Palace

So much more than a race bike

This focussed road speed merchant may owe its name to South London’s weekly world champs – Crystal Palace Crits, but the very features that make it suited to the technical race circuit shine through on the open road. Sharp handling and stability at speed make the Palace perfect for riders after a great handling ride.

Buy Palace Frameset

We have just received delivery of Palace framesets and all pre-ordered frames have now shipped. Due to increased demand, we have now sold all frames bar 3 x 50cm’s from this batch. We are accepting pre-orders on all sizes right now and pre orders should on or around October 7th. These will be a week to the UK so this is the second week in October to get a frame in your hands. Any remaining stock will be available close to the end of October allowing for the vagaries of international shipping, pirates and customs clearance.

Palace frameset: £650.00 - includes Frame, fork, headset and seat collar

The latest generation of formed aluminium tubing offers weight that beats all but the highest calibre carbon fibre at a mere 1200grams for a 56cm frame – and in a far more robust package, better suited to the rough and tumble of amateur racing.
An oversized front triangle, and tapered steerer set up make for a bike that rails the tightest of turns yet thin walls and our custom tubing profiles make for a bike that belies any filling-rattling memories of old aluminium frames. Topped off with a standard 27.2mm seatpost, this is an exceptionally pleasant place to spend many an hour alone in the lanes once any number has been unpinned.
At the end of the ride, home mechanic friendly external cable routing makes everyday maintenance a breeze and the tough anodised finish will keep up appearances long after the competitions paint chips.



• Triple butted, Custom shaped, 6069-T6 Aluminium frame
• Tough anodised finish.
• Full carbon-monocoque, 1:1/8th-1.5” steerer, fork
• CNC finished, Tapered, headtube
• clearance for 25-28c tyres
• PF86 bottom bracket shell
• Oval, Tapered chainstays
• 27.2 seatpost for improved comfort
• Full external cable routing for ease of maintenance
• FSA, #42 ACB headset (included)
• Angle Slotted seat clamp



Geometry

50 52 54 56 58
top tube (effective) 505 520 540 560 585
head tube 120 130 145 160 185
head angle 71.5 72 72.5 73 73.5
seat angle 74.5 74 73.5 73 72.5
seat tube c-t 495 515 525 540 560
chainstays 400 405 405 405 410
bb drop 70 70 70 70 70

Reach and Stack - in mm

  • 50cm - 360 / 520
  • 52cm - 366 / 528
  • 54cm - 373 / 540
  • 56cm - 386 / 562
  • 58cm - 397 / 577
